Three upgrades, one running order

Lights.Cover. Action.

Yes, in that order, and yes, on purpose. Three add-ons, three acts, and by the end of the third one they are playing together instead of just sitting in the same backyard. None of it is in the price of the pool and none of it is needed to swim. This is the difference between owning a pool and having the best backyard on the street.

01Lights

Everybody gets lights. Get the right ones.

A pool with no lights is a hole you cannot use after eight o'clock. This is the least expensive upgrade on the page and the one that changes the most, because it roughly doubles the hours you get out of the thing.

We standardise on one fixture: the Pentair MicroBrite Color LED, 12 volt, nicheless, 100 foot cord, model 620425. One answer, specified the same way on every job, which is how you end up with a crew that never has to guess.

3.5"
Long. One of the most compact 12V LED lights made
14
Settings: seven colour shows and five fixed colours
Pentair MicroBrite nicheless colour LED pool light
Pentair MicroBrite Color LED · 12V · model 620425
Why this one

No niche

Installs in any standard 1.5 inch wall fitting. No large traditional niche to deal with, which on a fiberglass shell genuinely matters.

Why this one

Fits anywhere

Three and a half inches means it goes on steps, benches, sun ledges, spas and narrow walls. It can face up in water as shallow as four inches.

Why this one

No hot spots

Pentair builds it for lighting uniformity rather than raw output, so you get even light instead of one bright patch and a lot of shadow.

Why this one

It talks to the pad

Connects to any Pentair automation system, including the Color Sync controller, so colour and shows are a control rather than a wall switch you flick twice.

How many, and where

Our lighting specification.

Fixture count is not a guess, but it is not a formula either. Pentair is explicit that perceived light depends on the model, the depth and angle it is set at, the pool finish, the shape and geometry, and how much other light is already in the yard. Here is where we start.

Downgrade
2

MicroBrite White LED

Elegant illumination for the homeowner who does not care about changing colour. Same fixture, same install, white light. Cheaper, and honestly still beautiful.

Standard package
2 to 3

MicroBrite Color, on Color Sync

For a typical 12 by 24 pool we start with two, positioned to throw light away from the house and the main seating sightlines rather than into your eyes. A third goes in when there is a substantial tanning ledge, steps, or another area that would otherwise sit in shadow.

Upgrade
4

Four light zoned layout

Separate zones for the pool, the sun ledge, the steps, the spa or a water feature, so each area can be lit on its own instead of all of them at once.

Standard model
Pentair MicroBrite Color LED, 12V, nicheless, 100 ft cord, model 620425
Cord options
50 ft (620424), 100 ft (620425) and 150 ft (620426). We standardise on the 100 so the truck carries one part
Fitting
Any standard 1.5 inch pool wall fitting. No niche required
Works in
Fiberglass, vinyl liner and gunite with the appropriate fitting. Ours is fiberglass
Control
Any Pentair automation system, including the Pentair Color Sync controller
Colours
Seven pre-programmed colour shows plus five fixed colours: blue, green, red, white and magenta
Also available
White LED and warm white, if colour changing is not your thing
Listing
UL listed. Pentair certifies its UL listed underwater lights for fresh water up to 6,000 ppm salinity
Buy it from us
MicroBrite is a Pentair TradeGrade product. Bought through a dealer and installed by a qualified installer it carries the full product warranty. Bought online it is limited to Pentair's 60 day warranty. That is Pentair's policy, not ours, and it is a good reason to let us supply it
One rule
Pentair says do not mix light models within one installation. If we add a light later it will be the same model

Specifications and product photography from Pentair. See the full MicroBrite page at pentair.com

02Cover

A cover you could stand on.

Not a tarp with water bags. An Integra automatic cover runs on tracks along the deck and closes with the flip of a switch, in one quiet motion, in about the time it takes to carry the cooler inside.

It is certified to ASTM F1346, the recognised standard for pool safety covers, which means it was tested as a real barrier rather than marketed as one. Integra engineers theirs to support 485 pounds. Read that number again and then think about a four year old and a dog.

485
Pounds it is engineered to support, per Integra
F1346
The ASTM safety cover standard it is certified to
A child playing beside a closed Integra pool cover

Safety

A proven protective barrier that keeps children and pets out of the water when you are not watching.

Integra cover retaining heat to extend the swim season

A longer season

It holds heat in overnight, so in Ohio you are swimming earlier in spring and later into fall.

Closed Integra cover keeping leaves out of a pool

Nothing gets in

Leaves, dirt and debris stay on top of the cover instead of on the bottom of your pool.

Reduced pool maintenance with an Integra cover

Less upkeep

Less evaporation, less skimming, less strain on the equipment. More of the summer spent in the water.

Certification
ASTM F1346, the recognised standard for pool safety covers, tested for strength, security and performance
Perimeter
Tracks engineered to close gaps and seal tight along the deck line
Surface
Designed to shed water rather than let puddles collect on top of the cover
Operation
Authorised control options only, so it cannot be opened by whoever wanders up to it
Built for
Sun, storms and seasonal extremes
Worth knowing
Integra is part of the Explore Industries group, the same parent company as EvoPools, so the cover and the shell come from the same family

Video and photography courtesy of Integra Pool Covers. Cover colours and sizing are confirmed at the measure visit. See the colour range at integrapoolcovers.com

03Action

The pool, run from your phone.

Hayward OmniLogic is the panel that replaces every dial, timer and mystery switch on your equipment pad with one app. Pump speeds, heater, water features, salt, lighting circuits, schedules. Set a theme called Friday Night and the pool sets itself.

It also answers to Alexa, which sounds like a gimmick right up until you are standing in the kitchen with wet hands telling the pool to warm up.

16
Variable speed pumps it controls without using a relay
20
Relays it expands to, from four out of the box
The Hayward OmniLogic automation panel
Hayward OmniLogic · SKU HLBASE
The app
Control the whole equipment pad, set schedules and themes, monitor it and adjust from anywhere
Interface
Icon based, which Hayward calls the most intuitive on the market and which mainly means your spouse will actually use it
Voice
Works with Amazon Alexa
Pumps
Full control of up to 16 variable speed pumps, no relays consumed
Expandable
Four relays out of the box, up to 20 with the HLRELAY, HLRELAYBANK and HLEXPAND modules
Lighting
Switches and schedules your lighting circuits. One app colour control is native to Hayward's own ColorLogic lights, so if choosing colour from the same app matters more to you than our standard fixture does, tell us at the measure visit and we will spec the matched pair instead
Salt
Salt ready, and lets you run salt levels down as low as 800 ppm
Chemistry
Works with Hayward Sense and Dispense to hold your chemical balance automatically
Remotes
Compatible with the wireless waterproof, wall mount and spa side Omni remotes
Warranty
Three year parts and one year labour, and Hayward lists three plus years parts and labour when sold by a Hayward Rewards partner
Availability
Expert Line, which means you cannot buy it online. It comes through a pool professional, which is us

Specifications and product photography from Hayward. See the full product page at hayward.com

Why all three, and not just one

Then they start playing together.

This is the part that sells itself. OmniLogic has a setting called Automatic Cover Scale-Back Mode. When an electronic cover closes, the panel automatically dials back the pump, the chlorinator and the heater, because a covered pool does not need the same run time, the same chlorine or the same heat to stay ready.

So the cover protects your family, the panel turns that into lower running costs every single night, and the lights come up on a schedule you set once. Three upgrades, one running order, and nobody has to remember to do anything.

A Friday night, in five moves
  1. Six o'clock. The schedule brings the lights up as the sun drops.
  2. Everybody swims. Nobody touches a thing on the equipment pad.
  3. Last one out flips the cover shut on the way inside.
  4. OmniLogic sees the cover close and scales the pump, chlorinator and heat back on its own.
  5. Morning. The cover opens, everything returns to normal, and the pool is ready.
Encore

Want to bringthe heat?

Everything above makes the pool better. A heater makes the season better. In Central Ohio the water is honestly swimmable from about Memorial Day to Labor Day. Add a heater and you are in it in early May and still in it in the middle of October. That is sixty-plus days a year you already paid for and never got.

It runs on the same OmniLogic panel from act three, so heat is a setting in the app rather than a dial on the pad, and it scales itself back when the cover closes.

60+
Extra swimmable days a season, earlier open and later close
~$4
A day to run the cheapest option in shoulder season
Where that four dollars comes from
Cheapest type to run
Electric heat pump
Example unit
140,000 BTU
Electrical draw
about 6.3 kW
Run time, holding temperature
about 4 hrs/day
Electricity used
about 25 kWh/day
Ohio residential rate
about 17¢/kWh
Cost per day
about $4.28
Sixty extra days
about $257

An estimate, not a quote, and we would rather show you the arithmetic than a number with no working. Real cost moves with your rate, the weather, the size of your pool, the temperature you hold, and whether the cover is closed. A cover is the single biggest lever, which is why it is act two. Gas heats three to five times faster and costs meaningfully more per day to run; Hayward puts heat pump operating costs at 50 to 75 percent below gas.

Cheapest to run

Electric heat pump

Pulls warmth out of the air instead of burning anything. Slowest to raise temperature, by far the cheapest to hold it, and it wants outdoor air above about 50°F to work at its best. The right answer for most people in this market.

Fastest to heat

Natural gas

On demand heat, three to five times faster to come up to temperature. The pick if you swim on impulse or on weekends rather than every evening. Needs a gas line run to the pad.

No gas line needed

Propane

The same speed and the same behaviour as natural gas, fed from a tank instead of a utility line. The answer when there is no gas at the house.

We fit Hayward heaters in all three fuels, and we are not going to bury you in model numbers here. Sizing depends on your pool, your yard and how you actually use it, so we spec the exact unit at the measure visit and it goes on the quote as its own line. See the Hayward heater range

Adding them

Every act quoted flat, before you sign.

None of this is in the price of the Everest, the Maldives, el Capitan or the Sacred, and none of it is a surprise later. Ask at the measure visit and each act goes on the written quote as its own line, lights and cover and automation and heat, so you can see exactly what each one adds and take only the ones you want.

Let’s dig The four pools first
